AST3010 Portable Tri Roller Swager

    Original Aero Staking Bearing Swaging Tool

The AST3010 is a genuine Aero Staking product, designed for bearing installation and bearing retention in aerospace applications. This portable tri-roller swaging tool adheres to stringent industry specifications, including BAC5435, NAS0331 Method 200, BPS4162, PS17031, CSMP023, SS8743, FH-19, and 03-03-012, ensuring high reliability and performance.

Tool Compatibility & Specifications

• For Bearing Number: MS14103-8

• Bearing Groove Pitch Diameter (PD): 0.900

• Bearing Inner Diameter (ID): 0.500

• Standard Outer Envelope of Tool: Diameter 1.500” OD

Tool Components and Features

• Flat-Surfaced Locating Fixture (Primary): Used for the first swage

• Angled (Conical) Locating Fixture (Secondary): Used for the second swage

• Roller Swaging Fixture (Head)

Ideal for On-Wing Applications

The AST3010 portable tri-roller bearing swaging tool is designed specifically for on-wing repairs. It easily fits into tight spaces, making it perfect for bearing retention, installation, and bearing replacement operations on aircrafts. It is a must-have tool for aerospace professionals working on-site or in restricted areas.

Lightweight, Mobile, and Easy to Maintain

• No power tools required

• Light and easy to handle, ensuring swift operation in the field

• Low maintenance with no weak links for long-term use

Equipment Required: NO POWER TOOL NEEDED

This manual tool is simple yet efficient, ensuring that you can complete bearing installation and retention without needing additional power equipment.
