AST 3013
Original Aero Staking Portable Tri-roller Swaging Tools
AST3013 is a genuine Aero Staking product. Portable tri-roller swaging tool meets the requirements for bearing installation and retention of main specifications such as BAC5435, NAS0331 Method 200, BPS4162, PS17031, CSMP023, SS8743, FH-19, 03-03-012
For Bearing Number: MS14101-10
Bearing Groove Pitch Diameter (PD): 1.063
Bearing Inner Diameter (ID): .625
Standard Outer Envelope of the Tool: Dia 1.750” OD.
Description of the Tool:
The Drill Press Swaging Tool is made of Aerospace Quality, treated, and coated tool steel; it consists of the following:
- The flat-surfaced locating fixture (primary) – used for the first swage
- Angled (conical) surfaced locating fixture (secondary) – used for the second swage
- Roller Swaging Fixture (head)
This tool is used primarily for small and large batch production, bearing retention, installation, and bearing replacement operations.
Standard portable swaging tools are for bearing installation in open spaces, with no tool maneuverability limitations. If you have any obstacles around the bearing, such as close walls, tabs, counterbores, wide housing, oversized chamfers, etc., please let us know before you order a standard portable tri-roller swaging tool.
Equipment Required:
- Standard knee mill, drill press, manual or CNC milling machine tool features ½ Dia shank
AST 3013
Original Aero Staking Portable Tri-roller Swaging Tools
AST3013 is a genuine Aero Staking product. Portable tri-roller swaging tool meets the requirements for bearing installation and retention of main specifications such as BAC5435, NAS0331 Method 200, BPS4162, PS17031, CSMP023, SS8743, FH-19, 03-03-012
For Bearing Number: MS14101-10
Bearing Groove Pitch Diameter (PD): 1.063
Bearing Inner Diameter (ID): .625
Standard Outer Envelope of the Tool: Dia 1.750” OD.
Description of the Tool:
The Drill Press Swaging Tool is made of Aerospace Quality, treated, and coated tool steel; it consists of the following:
- The flat-surfaced locating fixture (primary) – used for the first swage
- Angled (conical) surfaced locating fixture (secondary) – used for the second swage
- Roller Swaging Fixture (head)
This tool is used primarily for small and large batch production, bearing retention, installation, and bearing replacement operations.
Standard portable swaging tools are for bearing installation in open spaces, with no tool maneuverability limitations. If you have any obstacles around the bearing, such as close walls, tabs, counterbores, wide housing, oversized chamfers, etc., please let us know before you order a standard portable tri-roller swaging tool.
Equipment Required:
- Standard knee mill, drill press, manual or CNC milling machine tool features ½ Dia shank
